Brand Name:
pray-med
Certification:
CE
Model Number:
Hamilton 950185
950185 Hamilton c6/G5/T1 Flow Sensor with adapter with 282323 adapter
Product Description
|
Properties |
Medical Materials & Accessories |
|---|---|
|
Category |
Flow Sensor |
| Latex-free | Yes |
| Packaging Type | Bag |
| Packaging Unit | 1 |
| Compatible for | HAMILTON-C6/S1/G5/C3/C2/C1/T1/MR1 GALILEO, RAPHAEL |
| Diameter (ID, OD [mm]) / Description | Material | ||
| 1 | Connector | OD15, ventilator side | PSU (nature) |
| 2 | Tubing | -- | Silicone |
| 3 | Connectors for tubing | Differential pressure measurement | PSU (nature) |
| 4 | Individual serial number | -- | -- |
| 5 | Connector | OD22/ID15, patient side | PSU (nature) |
| 6 | Direction index | -- | -- |
| 7 | Flap | -- | Steel 1.4310 |
Details
| Flow | 0 to 180 l/min |
| Dead space | < 11 ml (functional) |
| Resistance | < 0.027 cmH2O/(l/min) over the complete flow range (-180 l/min to 180 l/min) |
| Weight | Approx. 15 g without tubing, 72 g with 188 cm tubing |
| Material | Complies with ISO 10993-1:2009 (biocompatibility) and Directive 2011/65/EU (RoHS). Does not contain natural rubber latex, DEHP, or BPA. |
| Accuracy | For calibrated flow sensor volume-related parameters: HAMILTON-C1/T1/MR1/C2/C3/C6 ventilators: ± 10% or ± 10 ml (whichever is greater) HAMILTON-G5/S1 ventilators: ± 15% or ± 20 ml (whichever is greater) |
