| Brand Name: | edan |
| Model Number: | F6 / F9 / F2 / F3 / cadence |
| MOQ: | 1pcs |
| Price: | as discussed |
| Packaging Details: | 1pcs / bag |
| Payment Terms: | T/T, Western Union |
Edan fetal toco transducer probe for F3 / F2 / F6 / F9 / Cadence II CTG machine
Technique spefication
| Technical Parameter | Connector type | 6pin |
| Patient end | TOCO | |
| Compatible brand | Edan | |
| Material | TPU | |
| Cable color | Gray | |
| Other | Compatible | |
| Compatible model | Cadence II / F2 /F3 /F6 / F9 | |
| Warranty | 1 year | |
| packing | 1 pcs/bag | |
| Delivery time | 3-5 working days | |
| Application | Fetal monitor | |
| Warranty | 6 months | |
Applicable scope: fetal heart rate, fetal and uterine pressure measurement
Technical parameter:
Ultrasonic probe FHR
Nominal frequency: 1 MHz
Operating frequency: 1 MHz + 10%
Peak negative pressure: P_ < 1 MPa
Output beam intensity: Iob 20 mw/cm2
Spatial peak time average sound intensity: Ispta 100 mw/cm2
Spatial mean time average sound intensity: Isata = 10 mw/cm2
Fetal heart rate range: 50 BPM to 240 BPM (BPM: beats per minute)
Resolution: 1 BPM
Accuracy: + 2 BPM
Pressure probe TOCO (pressure parameter)
TOCO range: 0 ~ 100%
Resolution: 1%
Nonlinear error: less than 10%
Zero mode: Manual
|
|
